Stainless Steel Strip
The stainless steel strip is simply an extension of the ultra-thin
stainless steel plate. It is mainly a narrow and long steel plate
produced to meet the needs of industrialized production of various
metal or mechanical products in different industrial sectors.
Cold rolled strip
① Using "stainless steel strip/coil" as raw material, it is rolled
into a product by a cold rolling mill at room temperature.
Conventional thickness <0.1mm～3mm>, width
<100mm～2000mm>;
②["Cold-rolled steel strip/coil"] has the advantages of smooth
surface, flat surface, high dimensional accuracy and good
mechanical properties. Most of the products are in coils and can be
processed into coated steel plates;
③Cold-rolled stainless steel strip/coil production process:
⒈pickling→⒉normal temperature rolling→⒊process
lubrication→⒋annealing→⒌flattening→⒍finish cutting→⒎packing→⒏to the
customer.
Hot rolled strip
① The hot rolling mill produces strip steel with a thickness of
1.80mm-6.00mm and a width of 50mm-1200mm.
②【Hot-rolled steel strip/sheet】has the advantages of low hardness,
easy processing and good ductility.
③Hot-rolled stainless steel strip/coil production process:
⒈pickling→⒉high-temperature rolling→⒊process
lubrication→⒋annealing→⒌flattening→⒍finish cutting→⒎packing→⒏to the
customer.
The difference
①The strength and yield ratio of the cold-rolled steel strip are
good, and the ductility and toughness of the hot-rolled steel strip
are good.
②The surface quality, appearance and dimensional accuracy of
cold-rolled steel strips are better than those of hot-rolled steel
strips.
③ The thickness of cold-rolled steel strip is ultra-thin, and the
thickness of hot-rolled steel strip is larger.
Like other materials, the physical properties of stainless steel
strip mainly include the following three aspects: thermodynamic
properties such as melting point, specific heat capacity, thermal
conductivity and linear expansion coefficient, electromagnetic
properties such as resistivity, electrical conductivity and
magnetic permeability, and Young's modulus of elasticity ,
stiffness coefficient and other mechanical properties. These
properties are generally considered to be inherent properties of
stainless steel materials, but are also affected by factors such as
temperature, degree of processing and magnetic field strength.
Generally speaking, stainless steel has lower thermal conductivity
and higher resistance than pure iron, and the properties such as
linear expansion coefficient and magnetic permeability vary
according to the crystal structure of stainless steel itself.
| Stainless Steel Strip Specifications |
| Item | Stainless steel strip |
| Grade | 201, 304, 316, 316L, 410, 430, etc |
| Standard | JIS, AISI, ASTM, DIN, TUV,BV,SUS,etc |
| Thickness | 0.25 - 3mm |
| Width | 600mm - 1500mm |
| Length | 2000/2438/3048mm |
| Size | 1000mm*2000mm, 1219mm*2438mm, 1219mm*3048mm, or as required |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair
line, sand blast, Brush, etching, etc |
| Application | Interior/exterior/architectural/bathroom decoration, elevator
decoration, hotel decoration, kitchen equipment, ceiling, cabinet,
kitchen sink, advertising nameplate |
| Lead time | 7 to 25 working days after the receipt of 30% deposit |
| Payment terms | 30%TT for deposit, 70% balance before shipment or LC at sight |
| Packing | Wooden pallet or according to customer's request |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| 201 | .15 Max | 5.5 - 7.5 | 1.00 Max | .060 Max | .030 Max | 16 - 18 | | 3.5 -5.5 | .25 Max |
| 202 | .15 Max | 5.5 - 7.5 | 1.00 Max | .060 Max | .030 Max | 16 - 18 | | 3.5 -5.5 | .25 Max |
| 301 | 0.15 max | 2.00 max | 1.00 max | 0.045 max | 0.030 max | 16-18 | | 6–8 | 0.10 |
| 302 | 0.15 | 2.00 max | 0.75 | 0.05 | 0.03 | 17–19 | - | 8–10 | 0.10 |
| 302B | 0.15 | 2.00 max | 2.0–3.0 | 0.05 | 0.03 | 17–19 | - | 8–10 | - |
| 304 | 0.08 | 2.00 max | 0.75 | 0.05 | 0.03 | 18-20 | - | 8-10.5 | 0.10 |
| 304L | 0.03 | 2.00 max | 0.75 | 0.05 | 0.03 | 18-20 | | 6–12 | 0.10 |
| 304H | 0.04-0.01 | 2.00 max | 0.75 | 0.05 | 0.03 | 18-20 | | 8-10.5 | - |
| 310 | 0.25 | 2.00 max | 1.50 | 0.05 | 0.03 | 24-26 | - | 19-22 | - |
| 310S | 0.08 | 2.00 max | 1.50 | 0.05 | 0.03 | 24-26 | - | 19-22 | - |
| 316 | 0.08 | 2.00 max | 0.75 | 0.05 | 0.03 | 16-15 | 2–3 | 10–14 | 0.10 |
| 316L | 0.03 | 2.00 max | 0.75 | 0.05 | 0.03 | 16-18 | 2–3 | 10–14 | 0.10 |
| 321 | 0.08 | 2.00 max | 0.75 | 0.05 | 0.03 | 17–19 | | 9–12 | 0.10 |
| 410 | .080 -.150 | 1.00 max | 1.00 Max | 0.04 | 0.030 max | 11.5-13.5 | | 0.75max | |
| Surface Finish | Definition | Application |
| 2B | Finished by heat treatment , picking or equipvalent cold rolling ,
followed by skin pass to obtain adequate luster surface. | With bright and smooth surface ,easy for further grinding to obtain
brighter surface ,suitable for medical instruments ,milk containers
,tableware and so on. |
| BA | Bright heat treatment after cold rolling. | Structual members .etc.kitchen utensil ,cutlery ,eleltric
applicances ,medical instruments ,building decorations ,etc. |
| NO.3/NO.4 | Polished with No.150-240 abrasives. | Milky food processing equipment , medicalinstruments ,building
decorations. |
| HL | Finshed by polishing with abrasives of suitable grain size to
obtain continuous streaks. | Building decorations ,such as elevators ,escalators ,door etc. |
| 6K/8K | A mirror-like reflective surface ,which is obtained by polishing
with successively finer abrasives and buffing extensively with all
gritlines are removed. | Buliding entrances,bulkding column casting ,elevator's wall doors
,counters,sculptures etc. |
| Stainless Steel Strip Applications |
- ✔ Stainless Steel Strip Used in Tractor
- ✔ Stainless Steel Strip Used in Automotive Trim
- ✔ Stainless Steel Strip Used in Stamped Machined Products
- ✔ Stainless Steel Strip Used in Cookware
- ✔ Stainless Steel Strip Used in Appliances
- ✔ Stainless Steel Strip Used in Kitchen
- ✔ Stainless Steel Strip Used in Foodservice Equipment
- ✔ Stainless Steel Strip Used in Sinks
- ✔ Stainless Steel Strip Used in Railway Cars
- ✔ Stainless Steel Strip Used in Trailers
| Stainless Steel Strip Processing |
The majority of normal processing can be performed on 201 Stainless
Steel Strip Fulilai Steel Group Offers Following Processing for
Stainless Steel Strip:
- ✔ Stainless Steel Strip Testing
- ✔ Stainless Steel Strip Cutting
- ✔ Stainless Steel Strip Grinding
- ✔ Stainless Steel Strip Forming Drilling/ Machining
We pack our goods in numerous ways based on the products, such
as:--
• Boxes and Crates
• Shrink-wrapped
• Carton boxes
• Wooden pallets
• Wooden boxes
• Wooden crates
