Color Coated PPGI SGCC PPGL DC51D Prepainted Cold Rolled Coil Color
Coated Galvanized Steel Iron Sheet Plate Coil Roll
PPGI Steel Coil Introduction
Galvanized steel is to prevent the steel plate surface from
corrosion to extend its service life, in the steel plate surface
coated with a layer of metal zinc, the zinc coated steel plate are
called galvanized sheet.
According to the production and processing methods can be divided
into the
1) hot dip galvanized steel. Thin plate in melting zinc bath, make
its surface adhesion of a layer of zinc sheet. At present mainly
adopts continuous galvanizing process, namely the continuous roll
of steel plate in the melt zinc plating tank made of galvanized
steel sheet;
(2) the alloying of galvanized steel. This kind of steel plate is
made by hot dip method, but after the slot, immediately heated to a
temperature of about 500 ℃, it make the generation of zinc and iron
alloy membrane. This kind of galvanized sheet with good coating of
sex and weldability;
The hot dip metallic coating process is also used to manufacture
steel sheet and coil with coatings of aluminium, or alloy coatings
of zinc/aluminium, zinc/iron and zinc/aluminium/magnesium which may
also be factory pre-painted. While GI may sometimes be used as a
collective term for various hot dip metallic coated steels, it more
precisely refers only to zinc coated steel. Similarly, PPGI may
sometimes be used as a general term for a range of metallic coated
steels that have been pre-painted, but more often refers more
precisely to pre-painted zinc coated steel.
Product Name | RAL Color Coated Galvalume Coil Aluzinc AZ150g/m2 PPGL Steel Coil
for Home Appliance |
Standard | AISI, ASTM, BS, DIN, GB, JIS |
Based Steel | Hot Dip Galvanized Steel, Hot Dip Galvalume Steel,Cold Rolled
Steel, Hot Rolled Steel |
Thickness | 0.12mm-2.0mm |
Width | 600mm-1250mm or Customized |
Surface Color | RAL, Wrinkled Pattern,Camouflage Pattern , Matte Pattern , High
Gloss Pattern , Flower or Grass Pattern, Wood Grain Pattern, Stone
Pattern, etc |
Quality | ISO 9001 Certification |
Coil Weight | 3-5 MetricTon Per Coil |
Payment | T/T L/C |
MOQ | 20 Tones |
Zinc coated steel substrate for PPGI is typically produced on a
continuous galvanizing line (CGL). The CGL may include a painting
section after the hot dip galvanising section, or more commonly the
metallic coated substrate in coil form is processed on a separate
continuous paint line (CPL). Metallic coated steel is cleaned,
pre-treated, applied with various layers of organic coatings which
can be paints, vinyl dispersions, or laminates. The continuous process used to apply these coatings is often
referred to as Coil Coating.
Product chemical component
Galvanized Steel 0.18mm-20mm thick galvanized steel sheet 2mm thick
Hot dip galvanized steel sizes galvanized sheet metal roll
bse metal type | Grade | CHEMICAL COMPOSITION % |
C | Si | Mn | P |
cold rolled steel sheet | DC51D+Z (St01Z, St02Z, St03Z) , DC51D+ZF | ≤0.10 | - | ≤0.50 | ≤0.035 |
DC52D+Z (St04Z), DC52D+ZF | ≤0.08 | - | ≤0.45 | ≤0.030 |
DC53D+Z (St05Z), DC53D+ZF | ≤0.08 | - | ≤0.40 | ≤0.030 |
DC54D+Z (St06Z), DC54D+ZF | ≤0.01 | ≤0.10 | ≤0.30 | ≤0.025 |
DC56D+Z (St07Z), DC56D+ZF | ≤0.01 | ≤0.10 | ≤0.30 | ≤0.025 |
hot rolled steel sheet | DD51D+Z (St01ZR, St02ZR) | ≤0.10 | - | ≤0.50 | ≤0.035 |
DD54D+Z (St06ZR) | ≤0.01 | ≤0.10 | ≤0.30 | ≤0.025 |
Packing & Delivery
Packing: Standard export seaworthy packing.
Shipping: by container or break bulk vessel. Max 25mt per 20ft
container.
Lead time: 20 days to 50 days acc to size and quantity
Payment terms: TT, LC at sight, Usance LC, DP etc.
Applications of PPGI Coils
Construction field used as building material: roofing tiles,
roofing components like gutter, balcony panel, warehouse, partition
board, windows and doors, fencing panel, corrugated sheets,
structural decking etc.
Auto Parts: car body shell, underpan, doors, fuel tank, stamping
parts etc.
Furniture Industry: wardrobe, desk, billboard, dustbin etc.
Electrical Industry: shell for electric appliances etc.
Standard & Grade:
ASTM A755-A755M--Standard Specification for Steel Sheet, Metallic
Coated by the Hot-Dip Process and Prepainted by the Coil-Coating
Process for Exterior Exposed Building Products
JISG 3312--Prepainted Hot-dip Zinc-Coated Steel Sheet and Strip
JISG 3322--Prepainted Hot-dip 55% aluminum-zinc alloy-coated steel sheets
and coils.
GBT12754--Prepainted Steel Sheet
